LA7500SB8 Powder Coating Oven (3' x 3' x 8')
LA7500SB8 Powder Coating Oven (3' x 3' x 8') is backordered and will ship as soon as it is back in stock.
Shipping, Tracking and Delivery
Shipping, Tracking and Delivery
Once your order is picked up by freight, we email you tracking information so that you can follow your shipment in transit. Freight carriers will have your name and number in case they need to contact you ahead of delivering. All freight that's shipped out is covered by insurance; in the case that your shipment is damaged, we will file an insurance claim on your behalf. Please note these claims can take anywhere between 1-2 months to fully process.
Description
Description
— Approved Applications
Trusted For Every Finish
Customers rely on our products across the full range of protective and performance coatings.
— LA7500SB8 · Technical Specifications
Everything You Need To Know
Max Temperature
500°F
Inside Working Space
36×37×96″
Shipping Weight
~675 lb
| Dimensions & Shipping | |
|---|---|
| Inside Working Dimensions | 36″ W × 37″ D × 96″ T (Nominal) |
| Outside Footprint | 48″ W × 48″ D × 100″ T (Nominal) |
| Shipment Size | 5′ W × 10′ D × 5′ T |
| Recommended Distance from Wall | 3″ |
| Power & Electrical | |
| Power Requirements | 208–240V / Single Phase / 56A Draw |
| Breaker & Required Wires | 60A or Greater / 2-Pole / 2 Hot, 1 Neutral, 1 Ground |
| Electrical Hook-Up | Hardwire (DIY) or Plug & Play (Optional) |
| Recommended # of Blower Fans | 2 |
| Performance & Controls | |
| Temperature Range | Ambient – 500°F |
| Included PID Controller Functions | Timer & Temperature Controls |
| Included & Support | |
| Ceiling Hanging | Included |
| Warranty | 1-Year Complete Parts Warranty |
Stationary Curing Oven 8' Inside Height
The LA7500SB8 Curing Oven is an industrial-grade oven that increases efficiency in the curing process of composite and other materials. This product offers accurate temperature control and even heat distribution. It is also able to effectively maintain temperature throughout the curing process to ensure consistent and even results for all finished products. This model of curing oven available from Light Armor can produce a maximum temperature of 500 degrees F, making it capable of handling the curing process for any kind of material.The galvanized metal used for this curing oven gives it rust-resistance and longevity, while also making the oven withstand the tough conditions of an industrial setting. It can cure epoxy resin, powder coating, carbon fiber, polymers, plastic composites, rubber, adhesives, thermoplastics, and more. You can expect the optimal cure with the temperature uniformity and fast cooling rate of this curing oven.
